Analog Polyphonic Synth

Full Description

Recreate the Golden Age of synthesis

Step back in time with the UB-Xa's Vintage Mode. This feature allows you to select from 8 synthesizer signatures, including the legendary OB-Xa and OB-8. With the UB-Xa, you can recreate the iconic sounds that shaped the music of the past and bring them into the present.

Limitless sound design

With 16 voices and 2 VCOs per voice, the UB-Xa gives you incredible flexibility and depth in your sound design. The oscillator sync mode adds a touch of complexity to your patches, allowing you to create rich harmonics and complex textures. Whether you're layering two different sounds or splitting the keyboard, the UB-Xa's multi-timbral capability opens up a world of sonic possibilities.

Faithful and authentic

The UB-Xa's VCOs and VCFs are based on the original 3340 and 3320 semi-conductor designs, ensuring an authentic and true-to-the-original sound. You'll find sawtooth, triangle, and square waveforms at your fingertips, with variable pulse width for added versatility. The selectable dual-slope 12/24 dB analog low-pass filter per voice with adjustable resonance allows for further tonal variety.

Expressive playability

Featuring 61 semi-weighted full-size keys with poly after-touch and velocity sensitivity, the UB-Xa offers a responsive and expressive playing experience. The velocity and after-touch can used to add further movement to your performances.

Endless sonic exploration

The UB-Xa boasts a flexible 8-channel modulation matrix, giving you the ability to modulate pulse width, oscillator pitch, and filter cutoff frequency. With 2 dedicated LFOs and 7 waveform shapes, you have even more control over your sound, allowing you to create intricate and evolving textures.

Real-time parameter editing

With 26 rotary controls and a high-quality LCD display, the UB-Xa offers direct and real-time access to all important parameters. The assignable preset recall switches make it easy to switch between your favorite sounds on the fly, giving you instant access to patches.

Features

• Analog polyphonic synthesizer based on the classic architecture of the OB-Xa
• Includes original factory patches to tap into the classic power of its predecessor
• Vintage mode with eight different voicings to recreate aging components, from Modern to Vintage to Gnarly
• 16 voices with two VCOs per voice and oscillator sync
• Bi-timbral design allows you to split or layer the keyboard between two different sounds
• VCO and VCFs based on recreations of the original 3340 and 3320 semiconductors that powered the original synth
• Both VCOs can create sawtooth, triangle, or square waveforms with pulse width modulation for tonal variety
• Dual slope analog low-pass filter with selectable 12 dB/octave and 24 dB/octave slopes and resonance
• 61 semi-weighted keys with polyphonic aftertouch and velocity sensitivity, for expressive playing
• Eight-channel modulation matrix for expanding patches and adding movement and depth
• Dual-layer arpeggiator and sequencer with real-time transposition of stored sequences
• Two dedicated LFOs with 7 waveform shapes for a wide range of modulation curves
• Two ADSR envelope generators per voice provide control over filter and amp
• Stereo VCA per voice allows for voice or layer panning for a wide, moving stereo field
• 26 rotary controls for fast, hands-on real-time patching
• Quality LCD display with encoder for easy menu and parameter editing
• Assignable preset recall switches for quickly loading new programs
• Spring-loaded pitch and modulation paddles for additional performance options
• 512 user memory slots with "compare and match" to make patch parameters match synth panel
• Servo-balanced outputs for crisp, accurate signal
• CV and pedal inputs for use with expression pedals and footswitches
• Compatibility with MIDI Polyphonic Expression (MPE) controllers for additional expression
• Full MIDI implementation with NRPN and CC control of parameters with bulk patch load and save

Specifications

• Product Code: UB-XA
• Number of Voices: 16-voice bi-timbral
• Type: Analog
• Oscillators: 32 (2 VCOs per voice)
• LFO: 2
• VCF: 1 low pass, 2-pole (12 dB/oct) or 4-pole (24 dB/oct), switchable
• Envelopes: VCA, VCF
• MIDI In/Out/Thru: 5-pin DIN/16 channels
• USB MIDI: USB 2.0, type B
• Main Output: 2 x 1/4" TRS, balanced, max. 22 dBu, Impedance: 50Ω
• Headphones: 1/4" TRS, stereo, max. 25 mW dBu, Impedance: 25Ω
• Foot Pedals:
  • Vibrato: 1/4" TRS, balanced
  • Filter: 1/4" TRS, balanced
• Foot Switches:
  • Sustain: 1/4" mono
  • Program Advance: 1/4" mono
  • Hold: 1/4" mono
• USB Type: Class-compliant USB 2.0, type B
• Supported Operating Systems:
  • Windows 7 or higher
  • Mac OS X 10.10 or higher

Manual Section

• Controls: Volume: 0 to 255, Balance, Master Tune
• Switches: Auto, Chord

Control Section

• Controls: Portamento, OSC 2 Detune
• Switches: Unison

Arpeggiator Section

• Controls: Rate
• Switches: Settings, Hold, On

LFO Section

• Controls: LFO Rate
• Switches: Waveform
• LED: Sine, Inverse Sawtooth, Square, Sawtooth, Sample & Hold, Trig, SMP

Modulation Section

• Controls: OSC 1 depth, OSC 2 depth
• Switches: OSC 1 freq, OSC 2 freq, Filter freq, OSC 1 PWM, OSC 2 PWM, Volume mod

Oscillator Section

• Controls: Frequency 1, Pulse width, Frequency 2
• Switches: Saw waveform 1, Pulse waveform 1, Sync OSC 2, F-ENV (envelope follow) OSC 2, Saw waveform 2, Pulse waveform 2, Shift

Keyboard Section

• Switches: Split (keyboard), Double (keyboard), Lower (keyboard), Upper (keyboard)

Sequencer Section

• Switches: Rest/tie, Record, Stop, Play/pause

Filter Section

• Controls: Frequency, Resonance, Modulation, Noise
• Switches: OSC 1, Half OSC 2, Full OSC 2, 4 Pole, Track

Envelope Section

• Controls: Attack (envelope), Decay (envelope), Sustain (envelope), Release (envelope), Attack (filter), Decay (filter), Sustain (filter), Release (filter)

Programmer Section

• Controls: Select encoder
• Switches: Compare, Manual, Write, Preset/value −, Preset/value +
• Display: 2 x line, 16-digit LCD display

Assignable Preset Recall Section

• Switches: 1/USB/MIDI, 2/Vel/aft, 3/Voice, 4/Mod

Keyboard and Controls

• Wheels: Pitch, Modulation
• Controls: Rate, Depth
• Switches: Waveform, OSC 1 mod, OSC 2 mod, OSC 2 only (bend), Amount (bend), Transpose down, Transpose up
• LED: Triangle, Square, Sawtooth, Inverse Sawtooth, Random, Sample & Hold
• Keyboard: 61 full-size keys with velocity and polyphonic aftertouch
